Screw Air Compressor Series-HANDE

HD- Series Direct Drive Fixed Speed

Product Model:HD-8——HD500

Motor Power：7.5KW-315KW

Volume flow：0.7m³/min- 50.0m³/min

Working pressure：0.8Mpa-1.25Mpa

Note: Other special standards can be customized. For more details, please consult us

Product Information

Product Features:

Adopts the third-generation high-efficiency screw compressor unit, featuring low speed, low noise, energy savings, and stable operation, with transmission efficiency close to 100%.Equipped with a specially designed low-speed motor, delivering 3-5% higher energy efficiency compared to similar products, and easy maintenance.Independent detachable low-speed fan and cooling system, offering long service life and adaptability to high-temperature environments up to 45°C.Intelligent control system&monitors pressure and temperature in real time to ensure stable output.

Application industry:

Automotive parts manufacturing (spraying, pneumatic tools, assembly lines), electronics and semiconductors (SMT Placement Machines, PCB cleaning, precision blowing), plastics and injection molding (blowing machines, injection molding machine auxiliary gas sources), food packaging (filling, labeling, vacuum packaging), gas transportation (nitrogen, carbon dioxide compression), petrochemical process compression (catalytic cracking, desulfurization system), thermal power plants (instrument air, valve control, ash removal system), gas transportation (pipeline pressurization, gas storage compression), Mining & Rock Drilling (Down-the-Hole Drilling Rigs, Pneumatic Breaking), mineral processing plants (flotation machines, pneumatic mixing), textiles (jet looms, yarn twisting), papermaking (pneumatic drying, paper slitting), Marine Applications (Main Engine Starting, Deck Tools, Pneumatic Control Systems), Rail Transportation (train braking, platform pneumatic equipment)

HD- Series Direct Drive Fixed Speed

Product Parameters:

Model	Exhaust pressure	Displacement	power	Ambient temperature	Exhaust port pipe diameter	Cooling method	weight	Dimensions
	Mpa	m³/min	KW/HP	℃	inch		Medical history	L×W×H(mm)
HD-8	0.8	1.0	7.5/10	-5～45	Rp1/2	Air cooling	197	900×670×880
	1.0	0.9
	1.25	0.7
HD-11	0.8	1.7	11/15	-5～45	Rp3/4	Air cooling	290	1080×750×1000
	1.0	1.5
	1.25	1.2
HD-15	0.8	2.1	15/20	-5～45	Rp3/4	Air cooling	306	1080×750×1000
	1.0	1.9
	1.25	1.7
HD-19	0.8	2.8	18.5/25	-5～45	Rp1	Air cooling	420	1380×850×1160
	1.0	2.2
	1.25	2.0
HD-22	0.8	3.4	22/30	-5～45	Rp1	Air cooling	424	1380×850×1160
	1.0	2.9
	1.25	2.6

Model	Exhaust pressure	Displacement	power	Ambient temperature	Exhaust port pipe diameter	Cooling method	weight	Dimensions
	Mpa	m³/min	KW/HP	℃	inch		Medical history	L×W×H(mm)
HD-30	0.8	4.5	30/40	-5～45	Rp1	Air cooling	455	1380×850×1160
	1.0	4.0
	1.25	3.6
HD-37	0.8	6.0	37/50	-5～45	Rp1-1/2	Air cooling	640	1500×1000×1330
	1.0	5.2
	1.25	4.5
HD-45	0.8	7.1	45/60	-5～45	Rp1-1/2	Air cooling	685	1500×1000×1510
	1.0	6.3
	1.25	5.6
HD-55	0.8	9.0	55/75	-5～45	Rp2	Air cooling	1130	1800×1250×1670
	1.0	8.2
	1.25	7.2
HD-75	0.8	12.0	75/100	-5～45	Rp2	Air cooling	1120	1800×1250×1670
	1.0	10.5
	1.25	9.0

Model	Exhaust pressure	Displacement	power	Ambient temperature	Exhaust port pipe diameter	Cooling method	weight	Dimensions
	Mpa	m³/min	KW/HP	℃	inch		Medical history	L×W×H(mm)
HD-90	0.8	14.8	90/120	-5～45	Rp2	Air cooled or water cooled	1430	1950×1250×1810
	1.0	12.5
	1.25	10.9
HD-110	0.8	19.5	110/150	-5～45	Rp2-1/2	Air cooled or water cooled	1810	2300×1470×1840
	1.0	15.5
	1.25	14.4
HD-132	0.8	22.1	132/175	-5～45	Rp2-1/2	Air cooled or water cooled	1880	2300×1470×1840
	1.0	18.5
	1.25	16.8
HD-160	0.8	26.0	160/200	-5～45	Rp2-1/2	Air cooled or water cooled	2300	2500×1600×1900
	1.0	22.6
	1.25	20.5
HD-185	0.8	30.0	185/250	-5～45	DN100	Air cooled or water cooled	4200	3650×2100×2280
	1.0	26.0
	1.25	23.2

Model	Exhaust pressure	Displacement	power	Ambient temperature	Exhaust port pipe diameter	Cooling method	weight	Dimensions
	Mpa	m³/min	KW/HP	℃	inch		Medical history	L×W×H(mm)
HD-200	0.8	32.8	200/280	-5～45	DN100	Air cooled or water cooled	4400	3650×2100×2280
	1.0	28.0
	1.25	26.0
HD-220	0.8	36.5	220/300	-5～45	DN125	Air cooled or water cooled	4700	3695×2100×2280
	1.0	33.2
	1.25	29.5
HD-250	0.8	40.8	250/350	-5～45	DN125	Air cooled or water cooled	4900	3695×2100×2280
	1.0	36.4
	1.25	33.2
HD-315	0.8	50.0	315/430	-5～45	DN125	Air cooled or water cooled	6800	4300×2365×2380
	1.0	44.5
	1.25	39.5

Note: The company's products are constantly being optimized, and the parameters are subject to change without prior notice; Different voltage and other special models can be customized, please consult the business.
